Model

ZH-XLW-225

Interior sizes

W600×D500×H750mm (customized)

Exterior sizes

W1150×D1150×1900mm (or so)

Temp. range

0ºC~80ºC

Controller

imported programmable 7inch touch screen

Material

inner and outer 304# stainless steel

Sample holder

Aluminum alloy frame base

Protection device

residual-current circuit breaker (RCCB) to control the warning for loop overload, thermal protection and water shortage protection.

Temp. deflection

±2ºC  (without lighting)

Humid. range

30%~98%R.H

Humid. deflection

±2.5%R.H(Humid.≥75%R.H); ±3%R.H(Humid.≤75%R.H)(without lighting)

Light source

imported full spectrum xenon arc lamp(average useful life 1600hrs)

Raining time

1~9999min (adjustable)

Raining period

1~240min, interval(cut)adjustable

lamp power

Test period for Temp., irradiation, condensation, spray can be adjustable

Lamp

1.8KW (2 pieces)

Wave length range

290-800nm (other point 300~400nm, 300nm / 400nm optional)

heating power (or so)

4.0KW

humidification (or so)

2.0KW

Light irradiance

1200w/m²

Distance between arc center and sample holder:

350~380mm

Revolving speed of sample holder

≥1r/min

Water spray period

a. spray time: 0~99h59min (Continuing or adjustable)
b. stop time: 0~99h59min, (Continuing or adjustable)

Lighting time

Continuing programming control available

Black panel temp.

85±3ºC

Cooling method

Mechanical wind cooling; Room temp. less than 26ºC is recommend, relative humid: ≤85%R.H; humid. and temp. tested after 2 hours under idle condition.
