Pressure

10、20、30、50 ton (optional)

Units

Temperature：℃、℉

Area：m2、cm2、mm2、ft2、in2

Energy：kgf、gf、tonf(long)、tonf(short)、lbf、ozf、kN、N、tonf(SI)

Pressure：bar、kgf/cm2、KPa、MPa、mm-Aq(4℃)、psi

Temperature

Room temperature~ 300℃

Size of heating plate

30×30 cm (or designated)

Heating time

50→150℃ take 18mins

Distance between heating plate

150 mm (Max.)

Cooling method

Use cooling system to rapidly cool upper and lower mold

Cooling time

150℃→60℃ 10mins

Steps can be set

Pre-press time, press time

Temperature can be set

Forming temperature, open mold temperature

Controller

7” touch screen

Display

Instant energy, temperature, diagram

Protection

Full cover, emergency stop button

Dimension

101×74×157 cm (W×D×H)

Weight

680 kg

Power

3 phase 220V/50 or 60HZ
