Temperature

Room temperature – 300℃

Temperature Control

2℃ increase per minute (adjustable)

Weight

Each station has the following weights:
0.1N×1, 0.2N×2, 0.5N×1, 1N×1, 2N×2, 5N×1, 10N×1

Delfection Reading

0.001~3.000 mm

Flexion Span

100 mm, 64mm (101.6mm for options)

Specimen Support’s Surface

R=3.0 mm (able to add the Vicat heat deflection test head)

Specimen Dimension

ASTM L=5”(127 mm), d=1/2 ”(12.7 mm), b=1/4”( 6.35 mm)
ISO edge wise L=120mm, d=10mm, b=4mm
ISO flat wise L=80mm, d=10mm, b=4mm
※Specimen deviation should be±0.1 mm

Stations

test stations: 1, 2, 3 stations

Temperature Equalization Method

Circulating flow

Cooling Method

Water cooling

Power

Single Phase 220VAC
