Capacity

3/6/10/15/50/100N-m

Torsion Resolution

1/100,000

Torsion Unit

MN-m、kN-m、N-m、N-cm、mN-m、kgf-m、
kgf-cm、kgf-mm、gf-cm、gf-mm、lbf-ft、lbf-in、ozf-in

Speed Unit

RPH、RPM、RPS

Angular Displacement Unit

deg、rad、rev

Power Type

Servo Motor

Test Speed

0.50 – 100.00 RPM (180.00 – 36000.00 deg/min) Digital Input

Test Direction

Clockwise/ Counter-clockwise

Angular Resolution

0.01°

Max. Sampling Rate

1200Hz

Test Space

Width : Max. 340mm
Height : Max. 400mm ( without grip)

Operation Mode

Operated by software

Power Supply

Single phase AC 220~240V，5A

Dimension

70 × 40 × 106 cm

Weight

75 kg
