Capacity

3/6/10/15/50N-m

Torsion Resolution

1/10,000

Torsion Unit

kN-m、N-m、N-cm、mN-m、kgf-m、kgf-cm、gf-cm、
lbf-ft、lbf-in、ozf-in、N-mm、cN-m、gf-mm

Speed Unit

rev/min(RPM), deg/min ( RPH, RPS for software)

Angular Displacement Unit

rad, deg ( rev for software)

Power Type

24V DC Motor

Test Speed

0.50 – 23.00 RPM (180.00 – 8280.00 deg/min)±1% Digital Input

Test Direction

Clockwise/ Counter-clockwise

Angular Resolution

0.01°

Max. Sampling Rate

1200Hz

Test Space

Width : Max. 340mm
Height : Max. 400mm ( without grip)

Operation Mode

Operated by display, and software for optional

Power Supply

Single phase AC 100 – 240V, 5A

Dimension

70 × 40 × 106 cm

Weight

70 kg
