Loading Force

Kgf

62.5Kgf, 100Kgf, 125Kgf, 187.5Kgf, 250Kgf,  500Kgf, 750Kgf, 1000Kgf, 1500Kgf, 3000Kgf

N

612.9N, 980N, 1226N, 1839N, 2452N, 4900N, 7355N, 9800N, 14700N, 29400N

Hardness Resolution

0.1HBW

Brinell Range

(8-650) HBW

Indentation Measurement

Automatically

Objective

1x And 2x

Software

Win 10 OS, MS Office

Brinell Measurement Software

BrinScan V3.0

Vertical Space

250mm

Horizontal Space

150mm

Dimension

622x313x992mm

Gross/Net Weight

200Kg/170Kg

Power Supply

AC 220V/110V±5%，50~60 Hz

Conform Standard

GB/T231.2, JJG150, EN-ISO 6506 ASTM E10-12  JIS Z2243

Accuracy

Hardness Range

Permitted Error

Repeatability

HBW≤ 125

≤± 3.5％

≤ 3.5％

125＜HBW≤225

≤± 2.5％

≤ 3.0％

HBW＞ 225

≤± 2.0％

≤ 2.5％
